LED-LH2KAC (semi-automatic exposure machine for anti-welding CCD counterpoint LED) |
|
|
content |
specifications |
|
electric power system |
AC380V 3 50/60HZ 12 KVA |
|
Light source system |
Light source: indirect water-cooled LED scanning light source group with output power of about 5KW. |
|
Uniformity |
More than 85% |
|
Effective exposure area |
E550*650mm f 630*730mm |
|
intensity of illumination |
More than 100~400mw/cm2 |
|
measure |
E305 x 355 mm to 550 x 650mm f305 x 355 mm to 630x730mm. |
|
Panel specification |
Film size: Wang 24"x28"f 26"*30 " |
|
Thickness: 0.2mm to 3.0mm. |
|
|
Exposure operation |
Single-sided double-frame operation, sequentially entering the exposure room. |
|
Negative alignment system |
1.CCD quantity: 4. |
|
2.CCD function: check the alignment accuracy and film expansion and contraction. |
|
|
3. Alignment form: PCB automatic alignment |
|
|
4. Fixation of negative film: groove type direct air adsorption, with direct air void above -680mmHg. |
|
|
5. Target form: dots on the upper negative, PC board PAD. |
|
|
6. Fixation of process board: Pin positioning |
|
|
7. Alignment of process board: automatic alignment of 15um (machine capacity) |
|
|
Mode of operation |
Operation mode: manually take and put the board. |
|
Machine size |
External dimension: W1685 x D3550x H1900 mm (reference dimension) |
|
Exposure frame |
Double exposure mesa, glass VS metal |
|
Table vacuum |
-200~-400mmHg |
|
cool |
LED light source: circulating indirect water-cooled |
|
Exposure room: air cooled |
|
|
Customer peripheral cooperation |
1. A clean environment with room temperature of 22 C+2 C and humidity of 55%+5%. |
|
2. Pure water: 30L |
|
|
3. External air source: 6Kgf/m2 (flow rate 60~200L/min) |
|
|
4. External ice water requirements: 7-11C/40 1/min 1 "pipe diameter x2, 1/2" pipe diameter x 1 |
|
