serial number |
accessory part |
project |
unit |
technical requirement |
|
one |
controller （UVSF81T） |
voltage |
220V |
|
|
2 |
|
Cooling mode |
Air cooling/water cooling |
|
|
three |
|
Control mode |
Screen Touch/Pedal /RS232/PLC |
|
|
four |
|
Adjustable range of irradiation head power |
10%-100% adjustable |
|
|
five |
|
Illumination mode |
Manual: always on after startup. |
|
|
six |
|
|
Automatic: Set irradiation countdown time (0.1-999.9s). |
|
|
seven |
|
|
Step: realize step irradiation (1-20 steps) |
|
|
eight |
|
|
Loop ladder: single/infinite |
|
|
nine |
|
communication control |
RS232 serial port: data reading and writing, LED switch control. |
|
|
10 |
|
|
I\O interface: LED switch control and running status output. |
|
|
11 |
|
Operating environment temperature/humidity |
0-45℃ (no condensation or freezing) |
|
|
12 |
|
Maintain ambient temperature/humidity. |
-10~60℃ 30~85%RH (no condensation) |
|
|
13 |
Irradiation head (SFHD series) |
LED type |
Ultraviolet LDE lamp bead |
|
|
14 |
|
UVLED service time |
About 20000 hours |
|
|
15 |
|
Heat dissipation mode |
Air cooling/water cooling |
|
|
16 |
|
Irradiation head material |
Sheet metal/aluminum alloy (water-cooled irradiation head) |
|
|
17 |
|
wavelength coverage |
365±5nm (customizable) |
|
|
18 |
|
External structure size |
371*260*151 |
|
|
19 |
|
Luminous size |
mm |
200*200 |
|
20 |
|
Suggested distance range |
mm |
15-20 |
|
21 |
|
Peak irradiation intensity (MAX) |
mw |
100-10000 |
|
22 |
|
Consume electric power |
W/H |
Affected by the number of lamp beads |
|
23 |
|
Operating environment temperature/humidity |
0-45℃ (no condensation or freezing) |
|
|
24 |
|
Maintain ambient temperature/humidity. |
-10~60℃ 30~85%RH (no condensation) |
|
|
25 |
Power cord |
electric cable |
m |
2M |
|
26 |
connecting line |
Towing cable |
m |
2M |
