LED parallel exposure machine UVE-M500 |
|
|
Power Supply |
AC220V 3 50Hz 60A |
|
Power cord |
16m2 * 4C |
|
Exposure uniformity |
More than 90% |
|
Effective irradiation area |
Effective irradiation area is 610L× 916W (mm) (18 "x24" x2). |
|
use |
Circuit exposure of PCB dry film and wet film |
|
Led light |
1.5KW×2 lamp |
|
Lighting time |
Within 3 sec |
|
Stabilization time |
About 8 minutes |
|
Lamp current |
1.3A/1.6A |
|
Water tank capacity |
36L+5L (heat exchange) |
|
External cooling water temperature |
20~30C |
|
water coolant |
standard configuration |
|
Table cooling |
Forced air cooling of cold air |
|
Table switching time |
4~5 Sec |
|
Vacuum absorption |
8~10 Sec |
|
Vacuum degree requirement |
More than -700mmHg |
|
External air pressure source |
2~3 kgf/cm2 |
|
Light quantity integrator |
Pro-face brand LCD touch display man-machine interface |
|
programmable logic controller |
Mitsubishi FX2N series |
|
Water pressure controller |
SNS-C102 |
|
Pressure regulator |
BN-3RT0-8A |
|
Refrigeration system |
6HP scroll compressor |
|
Machine size |
2755Lx1414Wx1693+100H (mm) |
